32
•
•
33
•
200 ~ 400
43
90
182
199
63
354
71
40mm MAX
51
28 Ø HOLE
38 Ø HOLE
51
28 Ø HOLE
T R I F LOW
UA D R O S Y S T E M
TF-KTQ821
WIDE SPREAD ELECTRONICALLY ACTIVATED TRIFLOW QUADRO SYSTEM
KEY FEATURES:
High grade, low lead, solid brass, plated to a thickness that exceeds
industr y standards, ensuring a deep protective coating, which is
luxuriously pleasing to the eye and resistant to wear
Dedicated waterway within a single spout for both hot and cold filtered
water delivery, thus avoiding cross-contamination
High per formance Swi s s -made ceramic fil ter car t ridge af fords the
benefit of both hot and cold filtered water, removing impurities down to
0.2 microns
Electronic but ton, with dual technology dispenses both hot and cold
filtered water
Intelligent LED control panel monitors filter cartridge performance and
indicates when replacement is required
Filter cartridge is easy to change — no tools required or need to open
the main unit
Various built-in safety features for peace of mind
Ultra efficient hot water management system effectively controls the
boiling cycle for reduced energy consumption
Easy to install unit; heater tank fits comfor tably under kitchen work top
Rotating spout
Five year warrant y on brassware
Two year warrant y on Quadro heater tank, and electronic but ton
SPECIFICATIONS
MODEL TF -KTQ821H
BRASSWARE TEMPERATURE RANGE — HOT & COLD
— FILTERED
Min 1ºC / 34ºF Max 85ºC / 185ºF
Min 1ºC / 34ºF Max 100ºC / 212ºF
RECOMMENDED WORKING PRESSURE
Min 1.7 Bar / 25.5 psi Max 5 Bar / 75 psi
FILTERED HOT WATER OUTLET TEMPERATURE
98˚C — AUTO CALIBRATING
ENERGY MANAGEMENT
INTELLIBOIL™ AUTOMATIC ENERGY SAVING MODE
CONTINUOUS SUPPLY (BOILING)
25 LITRES / HOUR, BASED ON COLD WATER INLET OF 15°C
TF-KTQ821 — AVAILABLE FINISHES
CHROME PLATE (CP); HOOK SPOUT (H)
ALTERNATIVE OPTIONS
ADDITIONAL FINISHES AVAILABLE AS BESPOKE ORDER
PLEASE REFER TO PAGE 58 FOR DETAILS
TRIFLOW QUADRO MODEL TF -KTQ821H IN CHROME PLATE (CP)
