18
•
•
19
•
15
30
45
60
90
105
120
840
855
870
100
99
98
97
90
ELAPSED TIME IN MINUTES
TEMPERATURE IN ˚C
T R I F LOW
UA D R O S Y S T E M
NEMKO
EN60335-1; EN60335-2-35
KIWA UK
CE
LV Directive
Two Years, parts and labour
APPROVALS:
WARRANTY:
HEATER TANK – LED DISPLAY FEATURES
New filter
Ambient filtered water in operation
Red light travels to the top
Filter requires replacement
POWER
BOILING
FILTRATION
APPROVALS AND WARRANTY
SYSTEM ON STANDBY
When the system is in Stand-by mode, the button will illuminate:
RED on the left side (HOT FILTERED) and GREEN on the right side (COLD FILTERED)
DISPENSING COLD FILTERED WATER
Press the right side of the button – GREEN LED Indicator –
Press again to stop the flow.
The button will then return to Standby.
DISPENSING HOT FILTERED WATER
Press the left side of the button for two seconds – RED LED indicator –
This will deactivate the safety mechanism; the RED indicator will begin to flash
Within two seconds, re-press and hold the button to dispense hot water heated to 98°C.
Release to stop flow. If a top-up is required, re-press button within two seconds.
Two seconds after dispensing, the system will return to standby.
ELECTRONIC BUTTON – KEY FEATURES
OTHER UNIQUE FEATURES
Intelliboil™Plus patented ultra-efficient hot water management system effectively controls the
boiling cycle for improved efficiency
In-built conditioner separates calcium from chalk thus reducing limescale build-up
Easy installation with auto-commissioning and calibration
Dry start and boil dry protection
Detachable steam condensing chamber for easy service access
MAINS WATER IN
ANTENNA
VARIABLE FREQUENCY SIGNAL
CONDITIONED
WATER OUT
IN-BUILT WATER CONDITIONER
INTELLIBOIL™ ENERGY MANAGEMENT
HEATER TANK – SPECIAL FEATURES
