38
•
•
39
•
40mm MAX
35 Ø HOLE
FILTERED IN G 3/8”
COLD IN G 1/2”
HOT IN G 1/2”
140
140
64
136
238
379
T R I F LOW
UA D R O S Y S T E M
TRIFLOW QUADRO MODEL TF -KTQ837H IN CHROME PLATE (CP)
TF-KTQ837
MONOBLOC MECHANICALLY ACTIVATED TRIFLOW QUADRO SYSTEM
KEY FEATURES:
SPECIFICATIONS
MODEL TF -KTQ837H
High grade, low lead, solid brass, plated to a thickness that exceeds
industr y standards, ensuring a deep protective coating, which is
luxuriously pleasing to the eye and resistant to wear
Employing unique Triflow three lever manual operating system with
electronic control to dispense hot filtered water
Dedicated waterway within a single spout for both hot and cold filtered
water delivery, thus avoiding cross-contamination
Fluhs™ 1 /4 turn precision ceramic valves
High per formance Swiss-made ceramic filter car tridge af fords the
benefit of both hot and cold filtered water, removing impurities down to
0.2 microns
Intelligent LED control panel monitors filter cartridge performance and
indicates when replacement is required
Filter cartridge is easy to change — no tools required or need to open the
main unit
Various built-in safety features for peace of mind
Ultra efficient hot water management system effectively controls the
boiling cycle for reduced energy consumption
Easy to install unit; heater tank fits comfortably under kitchen work top
Rotating spout
Five year warrant y on brassware
Two year warrant y on Quadro heater tank and electronic components
BRASSWARE TEMPERATURE RANGE — HOT & COLD
— FILTERED
Min 1ºC / 34ºF Max 85ºC / 185ºF
Min 1ºC / 34ºF Max 100ºC / 212ºF
RECOMMENDED WORKING PRESSURE
Min 1.7 Bar / 25.5 psi Max 5 Bar / 75 psi
FILTERED HOT WATER OUTLET TEMPERATURE
98˚C — AUTO CALIBRATING
ENERGY MANAGEMENT
INTELLIBOIL™ AUTOMATIC ENERGY SAVING MODE
CONTINUOUS SUPPLY (BOILING)
25 LITRES / HOUR, BASED ON COLD WATER INLET OF 15°C
TF-KTQ837H — AVAILABLE FINISHES
CHROME PLATE (CP); HOOK SPOUT (H)
ALTERNATIVE OPTIONS
ADDITIONAL FINISHES AVAILABLE AS BESPOKE ORDER
PLEASE REFER TO PAGE 58 FOR DETAILS
