22
•
•
23
•
FILTERED
G3/8"
COLD IN
G1/2"
HOT IN
G1/2"
408
208
121
158
231
T R I F LOW
UA D R O S Y S T E M
ZAHA HADID
FOR
TRIFLOW QUADRO IN CHROME PLATE - TF-KTQ807-CP
ZAHA HADID
FOR
TRIFLOW – TF - KTQ807
ELECTRONICALLY ACTIVATED TRIFLOW QUADRO SYSTEM
KEY FEATURES:
SPECIFICATIONS
MODEL TF -KTQ807
Iconic design by world-renowned architect Zaha Hadid
Available in a High or Low model that can be used in the kitchen or
bathroom depending on personal preference
High grade, low lead, solid brass construction, plated to a thickness that
exceeds industr y standards, ensuring a deep protective coating,
which is luxuriously pleasing to the eye and resistant to wear
Electronic but ton with dual technology dispenses both hot and cold
filtered water
Dedicated waterway within a single spout for both hot and cold filtered
water delivery, thus avoiding cross-contamination
High per formance Swi s s -made ceramic fil ter car t ridge af fords the
benefit of both hot and cold filtered water, removing impurities down to
0.2 microns
Intelligent LED control panel monitors filter cartridge performance and
indicates when replacement is required
Filter cartridge is easy to change — no tools required or need to open
the main unit
Various built-in safety features for peace of mind
Ultra efficient hot water management system effectively controls the
boiling cycle for reduced energy consumption
Easy to install unit; heater tank fits comfor tably under kitchen work top
Five year warrant y on brassware
Two year warrant y on Quadro heater tank, and electronic but ton
BRASSWARE TEMPERATURE RANGE — HOT & COLD
— FILTERED
Min 1ºC / 34ºF Max 85ºC / 185ºF
Min 1ºC / 34ºF Max 100ºC / 212ºF
RECOMMENDED WORKING PRESSURE
Min 1.7 Bar / 25.5 psi Max 5 Bar / 75 psi
FILTERED HOT WATER OUTLET TEMPERATURE
98˚C — AUTO CALIBRATING
ENERGY MANAGEMENT
INTELLIBOIL™ AUTOMATIC ENERGY SAVING MODE
CONTINUOUS SUPPLY (BOILING)
25 LITRES / HOUR, BASED ON COLD WATER INLET OF 15°C
TF-KTQ807 — AVAILABLE FINISHES
CHROME (CP); NICKEL (NI); BLACK NICKEL (BN);
MATT GOLD (MG)
ALTERNATIVE OPTIONS
ZAHA HADID FOR TRIFLOW — HIGH MODEL TF-KTQ808
